Description
30kVA/24kW
Input: 63A Breaker 3-Pole - Hardwired Input/Output - 16mm-2 Output: (1) Hard Wire 4-wire (3PH + G), (1) Hard Wire 5-wire (3PH + N + G), (1) Screw Terminals
Batteries: SYBT4 - Battery Module for Symmetra PX, Smart-UPS VT or Galaxy 3500
Communication Management: DB-9 RS-232, 10/100 Ethernet SNMP
Warranty: 2 years repair or replace
Runtime: Extended Runtime
Form Factor: Tower Only
Wiring Type: Three Phase Input / Output
Dimensions: 559 x 813 x 1499 (mm)
Part Number: SUVTP30KH4B4S
