VERTIV™ EDGE UPS
500VA - 3000VA

✓Line Interactive Sinewave UPS

✓ Rack / Tower Convertible

✓ 500VA to 3000VA

VERTIV™ EDGE UPS
500VA - 3000VA

Vertiv™ Edge UPS is a family of highly reliable, efficient, and flexible line interactive sinewave UPS power supply. Vertiv Edge UPS comes with various models ranging from 500VA to 3000VA in 1U, 2U, 3U, mini-tower, rack tower and rack-mount form factors (depending on model). With a high 0.9 PF, controllable outlets and extended runtime options, Vertiv Edge UPS is a cost-effective choice for protecting the server and networking equipment in distributed and Edge IT applications.

Distributed and edge data centers today are no less important to business success than large centralized data centers, given their role in supporting Internet of Things, cloud computing and other crucial applications. Server, networking and storage systems in edge data centers, then, deserve similar levels of power protection as traditional data center infrastructure. The Vertiv™ Edge line interactive UPS family is intended for distributed IT and edge applications that require reliable, efficient power protection. Edge UPSs support up to 6 extended battery cabinets (EBCs) in selected models, providing more runtime at full load than comparable competing UPSs. Edge UPSs are also easy to manage. Auto-detect features make the EBCs easy to add and configure, while a colorful, graphical LCD screen provides for easy, intuitive on-site management. Optional SNMP support is available and Vertiv Edge is compatible with the free Vertiv™ Power Insight software for remote management, enabling users to get status, configuration, UPS parameter data and more from anywhere via a web browser. Your UPS investment is protected by a standard 2-year warranty for both electronics and batteries.

BENEFITS

• Highly efficient: maximize power to IT loads, realize lifetime energy savings
• Wide range of form factors and flexible installation options
• Advanced battery protection and runtime optimization features
• Hot-swappable internal batteries – less downtime
• Withstands higher operating temperatures
• Low noise
• Remote monitoring and management capabilities

FEATURES

• High output PF=0.9 to maximize available power and protect more equipment
• High efficiency, up to 98% in line mode, to deliver energy savings
• 1U, 2U, 3U, tower, rack/tower form factors, with power ratings from 500VA to 3000VA, to address a broad range of power requirements
• Advanced AVR protection with 2x boost and 1x buck tap to protect the battery by smoothing out spikes, sags and brownouts
• Colour graphic LCD display
• Add up to 6 extended run battery cabinets to increase runtime
• External battery cabinets with auto-detection Rack/tower 3kVA model with short depth for flexible installation
• “Green mode” operation: in battery mode with small loads, the UPS will automatically shut down to protect batteries, optimize energy savings
• Programmable outlets to disable non-critical loads, optimize battery runtime
• Input breaker device for additional protection to the load in worst case failures
• Smart fan speed control for lower audible noise
• Remote connectivity via network interface or serial connection to monitor power consumption and configure user-defined alert notifications to prevent downtime
• Extend battery life with deep discharge protection RoHS and REACH compliant

VERTIV™ EDGE

Vertiv Edge UPS - 500VA / 450W / 230V - EDGE-500IRM1U
Vertiv Edge UPS - 500VA / 450W / 230V - EDGE-500IRM1U
Vertiv Edge UPS - 500VA / 450W / 230V - EDGE-500IRM1U
Vertiv Edge UPS - 500VA / 450W / 230V - EDGE-500IRM1U

Vertiv Edge UPS - 500VA / 450W / 230V - EDGE-500IRM1U

500VA/450W

Vertiv Edge 500VA 230V 1U Rack UPS

UPS Topology: Line Interactive
Power Rating: Extended Runtime
Form Factor: Rack
Input Voltage: 230V
Output Voltage: 200/208/220/230/240 V
Efficiency: 96%
Wiring Type: Single Phase
Dimensions (WxDxH): 438 x 380 x 44 (mm)
Part Number: EDGE-500IRM1U

$1,059.00
View Details
Vertiv Edge UPS - 1000VA / 900W / 230V - EDGE-1000IRM1U
Vertiv Edge UPS - 1000VA / 900W / 230V - EDGE-1000IRM1U
Vertiv Edge UPS - 1000VA / 900W / 230V - EDGE-1000IRM1U
Vertiv Edge UPS - 1000VA / 900W / 230V - EDGE-1000IRM1U

Vertiv Edge UPS - 1000VA / 900W / 230V - EDGE-1000IRM1U

1000VA/900W

Vertiv Edge 1000VA 230V 1U Rack UPS

UPS Topology: Line Interactive
Power Rating: Extended Runtime
Form Factor: Rack
Input Voltage: 230V
Output Voltage: 200/208/220/230/240 V
Efficiency: 97%
Wiring Type: Single Phase
Dimensions (WxDxH): 438 x 480 x 44 (mm)
Part Number: EDGE-1000IRM1U

$1,517.00
View Details
Vertiv Edge UPS - 1500VA / 1350W / 230V - EDGE-1500IRM1U
Vertiv Edge UPS - 1500VA / 1350W / 230V - EDGE-1500IRM1U
Vertiv Edge UPS - 1500VA / 1350W / 230V - EDGE-1500IRM1U
Vertiv Edge UPS - 1500VA / 1350W / 230V - EDGE-1500IRM1U

Vertiv Edge UPS - 1500VA / 1350W / 230V - EDGE-1500IRM1U

1500VA/1350W

Vertiv Edge 1500VA 230V 1U Rack UPS

UPS Topology: Line Interactive
Power Rating: Extended Runtime
Form Factor: Rack
Input Voltage: 230V
Output Voltage: 200/208/220/230/240 V
Efficiency: 97%
Wiring Type: Single Phase
Dimensions (WxDxH): 438 x 600 x 44 (mm)
Part Number: EDGE-1500IRM1U

$2,034.00
View Details
Vertiv Edge UPS - 1500VA / 1350W / 230V - EDGE-1500IRT2UXL
Vertiv Edge UPS - 1500VA / 1350W / 230V - EDGE-1500IRT2UXL
Vertiv Edge UPS - 1500VA / 1350W / 230V - EDGE-1500IRT2UXL
Vertiv Edge UPS - 1500VA / 1350W / 230V - EDGE-1500IRT2UXL

Vertiv Edge UPS - 1500VA / 1350W / 230V - EDGE-1500IRT2UXL

1500VA/1350W

Vertiv Edge 1500VA 230V 2U Rack UPS

UPS Topology: Line Interactive
Power Rating: Extended Runtime
Form Factor: Rack
Input Voltage: 230V
Output Voltage: 200/208/220/230/240 V
Efficiency: 97%
Wiring Type: Single Phase
Dimensions (WxDxH): 438 x 510 x 86 (mm)
Part Number: EDGE-1500IRT2UXL

$2,087.00
View Details
Vertiv Edge UPS - 2200VA / 1980W / 230V - EDGE-2200IRT2UXL
Vertiv Edge UPS - 2200VA / 1980W / 230V - EDGE-2200IRT2UXL
Vertiv Edge UPS - 2200VA / 1980W / 230V - EDGE-2200IRT2UXL
Vertiv Edge UPS - 2200VA / 1980W / 230V - EDGE-2200IRT2UXL

Vertiv Edge UPS - 2200VA / 1980W / 230V - EDGE-2200IRT2UXL

2200VA/1980W

Vertiv Edge 2200VA 230V 2U Rack UPS

UPS Topology: Line Interactive
Power Rating: Extended Runtime
Form Factor: Rack
Input Voltage: 230V
Output Voltage: 200/208/220/230/240 V
Efficiency: 97%
Wiring Type: Single Phase
Dimensions (WxDxH): 438 x 630 x 86 (mm)
Part Number: EDGE-2200IRT2UXL

$2,794.00
View Details
Vertiv Edge UPS - 3000VA / 2700W / 230V - EDGE-3000IRT2UXL
Vertiv Edge UPS - 3000VA / 2700W / 230V - EDGE-3000IRT2UXL
Vertiv Edge UPS - 3000VA / 2700W / 230V - EDGE-3000IRT2UXL
Vertiv Edge UPS - 3000VA / 2700W / 230V - EDGE-3000IRT2UXL

Vertiv Edge UPS - 3000VA / 2700W / 230V - EDGE-3000IRT2UXL

3000VA/2700W

Vertiv Edge 3000VA 230V 2U Rack UPS

UPS Topology: Line Interactive
Power Rating: Extended Runtime
Form Factor: Rack
Input Voltage: 230V
Output Voltage: 200/208/220/230/240 V
Efficiency: 97%
Wiring Type: Single Phase
Dimensions (WxDxH): 438 x 630 x 86 (mm)
Part Number: EDGE-3000IRT2UXL

$3,527.00
View Details
Vertiv Edge UPS - 3000VA / 2700W / 230V - EDGE-3000IRT3UXL
Vertiv Edge UPS - 3000VA / 2700W / 230V - EDGE-3000IRT3UXL
Vertiv Edge UPS - 3000VA / 2700W / 230V - EDGE-3000IRT3UXL
Vertiv Edge UPS - 3000VA / 2700W / 230V - EDGE-3000IRT3UXL

Vertiv Edge UPS - 3000VA / 2700W / 230V - EDGE-3000IRT3UXL

3000VA/2700W

Vertiv Edge 3000VA 230V 2U Rack UPS

UPS Topology: Line Interactive
Power Rating: Extended Runtime
Form Factor: Rack
Input Voltage: 230V
Output Voltage: 200/208/220/230/240 V
Efficiency: 97%
Wiring Type: Single Phase
Dimensions (WxDxH): 438 x 485 x 132 (mm)
Part Number: EDGE-3000IRT3UXL

$3,567.00
View Details
Vertiv Edge UPS - 750VA / 675W / 230V - EDGE-750IMT
Vertiv Edge UPS - 750VA / 675W / 230V - EDGE-750IMT
Vertiv Edge UPS - 750VA / 675W / 230V - EDGE-750IMT
Vertiv Edge UPS - 750VA / 675W / 230V - EDGE-750IMT

Vertiv Edge UPS - 750VA / 675W / 230V - EDGE-750IMT

750VA/675W

Vertiv Edge 750VA 230V Tower Mount UPS

UPS Topology: Line Interactive
Power Rating: Extended Runtime
Form Factor: Tower Only
Input Voltage: 230V
Output Voltage: 200/208/220/230/240 V
Efficiency: 96%
Wiring Type: Single Phase
Dimensions (WxDxH): 145 x 370 x 220 (mm)
Part Number: EDGE-750IMT

$947.00
View Details
Vertiv Edge UPS - 1000VA / 900W / 230V - EDGE-1000IMT
Vertiv Edge UPS - 1000VA / 900W / 230V - EDGE-1000IMT
Vertiv Edge UPS - 1000VA / 900W / 230V - EDGE-1000IMT
Vertiv Edge UPS - 1000VA / 900W / 230V - EDGE-1000IMT

Vertiv Edge UPS - 1000VA / 900W / 230V - EDGE-1000IMT

1000VA/900W

Vertiv Edge 750VA 230V Tower Mount UPS

UPS Topology: Line Interactive
Power Rating: Extended Runtime
Form Factor: Tower Only
Input Voltage: 230V
Output Voltage: 200/208/220/230/240 V
Efficiency: 96%
Wiring Type: Single Phase
Dimensions (WxDxH): 145 x 370 x 220 (mm)
Part Number: EDGE-1000IMT

$1,250.00
View Details
Vertiv Edge UPS - 1500VA / 1350W / 230V - EDGE-1500IMT
Vertiv Edge UPS - 1500VA / 1350W / 230V - EDGE-1500IMT
Vertiv Edge UPS - 1500VA / 1350W / 230V - EDGE-1500IMT
Vertiv Edge UPS - 1500VA / 1350W / 230V - EDGE-1500IMT

Vertiv Edge UPS - 1500VA / 1350W / 230V - EDGE-1500IMT

1500VA/1350W

Vertiv Edge 1500VA 230V Tower Mount UPS

UPS Topology: Line Interactive
Power Rating: Extended Runtime
Form Factor: Tower Only
Input Voltage: 230V
Output Voltage: 200/208/220/230/240 V
Efficiency: 96%
Wiring Type: Single Phase
Dimensions (WxDxH): 145 x 480 x 220 (mm)
Part Number: EDGE-1500IMT

$1,471.00
View Details

Contact us now!

For UPS systems there is design and engineering that will need to be done so it is best to book a site inspection or enquire directly with our team by filling out the form, emailing sales@upss.com.au or calling 1300 555 992.
